BARRETT 912 Single Wire Broadband Dipoles are ideal for base stations that require operation on multiple frequencies through out the HF spectrum using a single antenna. The 912 single wire broadband P/N BC 91201, can be mounted either in a horizontal or inverted 'V' configuration as illustrated in the following diagrams. In the horizontal configuration the minimum distance between the masts is 49 metres and the recommended mast height is 15 metres.
In locations with limited space the antenna can be mounted with the ends past the load resistors drooped down towards the ground. White nylon supports located just past the load resistors are provided to attach halyards for this configuration. In this configuration the minimum distance between masts is reduced to 33 metres.
